In 1845, German physicist Gustav Kirchhoff developed a pair of laws that deal with the conservation of current and energy within electrical circuits. These laws, commonly known as Kirchhoff's Voltage and Current Law, are two equalities that apply to the current and potential difference in the lumped element model of electrical circuits. Both of Kirchhoff's laws can be understood as corollaries of Maxwell's equations in the low-frequency limit. They are accurate for DC circuits and for AC circuits at frequencies where the wavelengths of electromagnetic radiation are very large compared to the circuits. Kirchhoff's Current Law states that the total current entering a junction or node equals the charge leaving the node, as no charge is lost. Kirchhoff's Voltage Law states that the voltage around a loop equals the sum of every voltage drop in the same loop for any closed network and equals zero.
| Characteristics | Values |
|---|---|
| Name | Kirchhoff's Laws, Kirchhoff's Circuit Laws, Kirchhoff's Rules, Kirchhoff's Voltage and Current Laws |
| Purpose | To deal with the current and potential difference (commonly known as voltage) in the lumped element model of electrical circuits |
| Inventor | Gustav Kirchhoff |
| Year | 1845 |
| Number of Laws | 2 |
| First Law | Kirchhoff's Current Law, Kirchhoff's First Law, Kirchhoff's Junction Rule |
| First Law Description | The total current entering a junction or node equals the charge leaving the node as no charge is lost |
| Second Law | Kirchhoff's Voltage Law, Kirchhoff's Second Law, Kirchhoff's Loop Rule |
| Second Law Description | The voltage around a closed loop equals the sum of every voltage drop in the loop and equals zero |
| Application | Applicable to all electric circuits, DC circuits, AC circuits with low frequencies |
